Active vs Inactive Relationships in Power BI

Power BI is a powerful data visualization tool that allows users to create complex data and interactive reports. When creating reports in Power BI, one of the features provided is to understand how relationships work between the tables. Relationships allow data to be linked between different tables and will assist in creating detailed, insightful reports. Within the Power BI data modeling, one can have active and inactive relationships, and understanding the differences between them is critical for building a reliable data model accurately and efficiently. In this blog, you’ll learn about active and inactive relationships, how they differ, and see real-world examples in detail.

Table of Contents:

What are Relationships in Power BI Data Models?

Before understanding active and inactive relationships, it is important to understand relationships in Power BI. A relationship in Power BI is a connection between two tables that is used to define the data and how they relate to each other. Relationships allow Power BI to use data from different tables to filter, aggregate, and create visuals. Creating a relationship between them helps to generate reports that show sales performance for different categories.

Power BI supports different types of relationships:

  • One-to-Many (1:N): One value in the first table is related to multiple values in the second table.
  • Many-to-One (N:1): Multiple values in the first table are related to a single value in the second table. Multiple values in the first table relate to a single value in the second table. In Power BI, this is essentially the same as One-to-Many.
  • Many-to-Many (N:N): Multiple values in both tables are related to each other.
Power BI for Professionals – Learn, Apply, and Stand Out!
Enroll now and future-proof your data career!
quiz-icon

What is an Active Relationship in Power BI?

The active relationship is the primary relationship that is used by Power BI to calculate and filter data automatically.

Example: We have a sample dataset from Intellipaat with the following two tables:

1. Students Table:

StudentID Name CourseID EnrollmentDate
1 Yash 101 2023-01-15
2 Kunal 102 2023-02-10
3 Akshat 103 2023-03-05

2. Courses Table:

CourseID CourseName Instructor Duration
101 Data Science Rahul Kumar 6 months
102 Machine Learning Anjali Patel 4 months
103 Cloud Computing Suresh Reddy 5 months

Note: We will make a relationship between the “Students” table and “Courses” table that Power BI will use by creating an active relationship using the “CourseID”.

Step 1: Load the dataset into Power BI

For loading the data, you need to click on Get Data >Text/CSV

Student Table:

student table

The Students table looks like this once we loaded it into Power BI.

Courses Table:

Course table

This is how the Courses table looks after loading it in Power BI.

Step 2: Go to Model View

To check the relationship, click on Model View and drag the CourseID field from the Students table and drop it on the Courses table

Step 2Go to Model View

Explanation: An active relationship is denoted by a straight line, which is used to join two tables.

Step 3: Result

Step 3 - Result

As you can see, Power BI already shows that a relationship has been created between the two tables.

Get 100% Hike!

Master Most in Demand Skills Now!

What is an Inactive Relationship in Power BI?

An inactive relationship is a secondary relationship activated with the Power BI DAX function temporarily whenever there is a need to perform a specific calculation.

Examples of Inactive relationships:

We will consider a third table called “Enrollments” of students of Intellipaat to establish an inactive relationship between the tables..

Enrollments Table:

StudentID CourseID EnrollmentDate CompletionDate
1 101 2023-01-15 2023-07-15
2 102 2023-02-10 2023-06-10
3 103 2023-03-05 2023-08-05

Step 1: Load the dataset into Power BI

Open Power BI and click on “Get Data”>Text/CSV

enrollment table

This is how the Enrollments table looks after loading it in Power BI.

Step 2: Creating a Date table

Click on “Modelling” tab >” New Table”>Write DAX formula in the formula bar

DateTable = CALENDAR(DATE(2023,1,1), DATE(2023,12,31))

After writing this formula in the formula bar, you have a new table that contains a date.

As you can see, there is no relationship between  Enrollments and DateTable

Step 3: Create the Relationship

Step3 create the Relationship

We will create a relationship by dragging the CompletionDate field from the Enrollments Table and dropping it on the Date field in the Date Table.

Step 4: Result

Step4Result

Explanation: Here, as you can see in this line, there is an inactive relationship between the Enrollments table and the Date Table attached with the help of a dotted line.

Step 5: Activating Inactive Relationships Using DAX

We will use the USERELATIONSHIP() function to activate inactive relationships.

Total Students Enrolled by Completion Date =
CALCULATE(
    COUNTROWS(Enrollments),
    USERELATIONSHIP(Enrollments[CompletionDate], DateTable[Date])
)
Formula bar

Explanation: Here, USERELATIONSHIP() is used to activate the inactive relationship between CompletionDate in the Enrollments Table and Date in the DateTable.

Step 6: Creating Visualization

Choose the bar chart from the visualization pane and drag the Month field from the Dates table on the axis.

Bar chart

Explanation: This graph is called a bar chart, which is used to show the total number of students who completed their course.

How to Identify Active vs Inactive Relationships in Power BI

In Power BI, relationships between tables can be either active or inactive, and identifying them is easy using the Model View.

  • Active relationships are shown with a solid line connecting two fields.
  • Inactive relationships are shown with a dotted line.

To view these:

  1. Go to Model View in Power BI.
  2. Look at the lines between tables:
    • Solid lines = Active relationships
    • Dotted lines = Inactive relationships

This visual distinction helps users understand how data is connected in their Power BI data modeling process.

When Should You Use Inactive Relationships in Power BI?

Use inactive relationships when you need to analyze data through an alternative path that is not covered by the active relationship. Power BI allows only one active relationship between two tables at a time, so additional relationships must remain inactive.

Common use cases:

  • When a table has multiple date fields (e.g., OrderDate and ShipDate)
  • When you want to perform time-based analysis on different date columns

To use an inactive relationship in a calculation, you must activate it temporarily using the USERELATIONSHIP DAX function:

CALCULATE(
COUNTROWS(Enrollments),
USERELATIONSHIP(Enrollments[CompletionDate], DateTable[Date])
)

This function is crucial when working with complex Power BI relationships across multiple tables.

Difference between Active Relationship and Inactive Relationship in Power BI

Aspect Active Relationship Inactive Relationship
Definition They are the primary relationship between two tables used automatically by Power BI. They are secondary relationships not used by Power BI automatically.
Usage Used for filtering and calculation automatically by Power BI. Used manually by the user for calculation and filtering.
Representation Active Relationships are denoted by the solid line. Inactive Relationships are denoted by a dotted line.
Default Behavior Automatically applied when filtering or calculating. It is used manually with the help of DAX functions.
DAX Activation There is no need to activate it. Use DAX function USERELATIONSHIP to activate it in a specific calculation.

Performance Tips for Using Relationships in Power BI

  • When working with large models, avoid creating relationships with the USERELATIONSHIP() function because this will slow your calculations down.
  • When you keep your model clean and do not create too many active and inactive relationships, the performance of related measures can improve.
  • Make sure that the relationship you created does not have loops, which can slow the model’s performance.
  • When creating a relationship, your data should be cleaned, and you should have no blanks or duplicates.

Best Practices for Power BI Relationships

To ensure a well-performing and reliable Power BI data modeling, follow these best practices:

  1. Choose the right relationship type – Understand and apply the correct Power BI relationship types (1:N, N:1, or N:N) depending on your data.
  2. Use only necessary relationships – Avoid creating too many relationships, especially inactive ones, as it can slow down your model.
  3. Avoid circular dependencies – Loops between relationships can break the model or cause errors.
  4. Clean your data – Ensure fields used in relationships have no blanks or duplicates.
  5. Use descriptive column names – This helps in easily identifying how tables are linked.

Conclusion

In Power BI, working with active and inactive relationships is an important part of building reports correctly and as efficiently as possible. Active relationships are the ones that Power BI uses by default for filtering the reports and calculations. In contrast, inactive relationships are secondary relationships and would normally not be used unless activated using Power BI DAX functions commands such as USERELATIONSHIP(). If you use inactive relationships correctly, you can build complex multi-table models that reveal more about your data.

To learn more about Power BI and its functions, check out this Power BI Course and also explore Power BI Interview Questions prepared by industry experts.

Active and Inactive Relationships in Power BI- FAQs

Q1. Can a table have multiple relationships with another table?

Yes, the table can have multiple relationships with another, but only one relationship can be active at a time.

Q2. How to activate inactive relationship in Power BI?

You can activate an inactive relationship with the help of the DAX formula called the USERELATIONSHIP() function.

Q3. Can I have two active relationships between the same tables?

No, you cannot have two active relationships, as it creates conflicts between tables.

Q4. Does using inactive relationships affect performance?

Yes, when you are working with large datasets and when there is more use of the USERELATIONSHIP() function.

Q5. Is it necessary to use a Date table in Power BI for filtering by dates?

A Date table isn’t strictly required, but it’s highly recommended for accurate time intelligence and consistent filtering across visuals

Q6. Why does Power BI not allow two active relationships between tables?

Power BI allows only one active relationship between two tables to avoid ambiguity in filter propagation.

Q7. What is USERELATIONSHIP() in Power BI and how is it used?

USERELATIONSHIP() is a DAX function used inside CALCULATE() to temporarily activate an inactive relationship for a specific calculation.

Q8. What happens if I don’t activate the correct relationship in Power BI?

If the correct relationship isn’t activated, your visuals may show incorrect or incomplete data due to filters not propagating as expected.

Q9. Can you use inactive relationships in visuals directly?

No, inactive relationships don’t affect visuals unless explicitly activated using USERELATIONSHIP() in a measure.

Q10. What happens if I don’t activate the correct relationship in Power BI?

You risk misleading results or broken filters if the wrong relationship is active.

Q11. When to use inactive relationships in Power BI

Use inactive relationships when you need multiple connections between tables but only one should be active at a time, like multiple date fields (OrderDate, ShipDate, etc.).
