What is Failure Mode and Effects Analysis (FMEA)?

In today’s fast-paced world, it is critical for businesses not to run into an unexpected failure or a quality issue.  Part of preventing risk is performing a Failure Mode and Effects Analysis. It helps teams discover potential issues, the significance of the issues, and make modifications to take action before the risk occurs. Failure Mode and Effects Analysis (FMEA) is used in manufacturing, healthcare, electronics, and other industries where identifying and resolving errors can improve performance. In this blog, you will explore what FMEA is, its importance for businesses, its types, and the steps for implementing FMEA in detail.

Table of Contents:

• What is Failure Mode and Effects Analysis (FMEA)?
• Types of Failure Mode and Effects Analysis
• FMEA Levels and Scope
• Why and When to Perform FMEA
• How to Perform Failure Mode and Effects Analysis
• Tools and Software for FMEA
• Failure Mode and Effects Analysis Examples
• Benefits of Failure Mode and Effects Analysis
• Challenges and Limitations of FMEA
• Best Practices for FMEA Implementation
• Conclusion

What is Failure Mode and Effects Analysis (FMEA)?

Failure Mode and Effects Analysis is a technique that allows you to identify problems and fix them before they happen. It is a technique that helps teams evaluate how a process, product, or system can fail and the consequences of failure. This method aims to decrease risk, increase quality, and improve the safety of a process. As an example, in manufacturing, engineers perform FMEA on a machine to identify any weaknesses in the machine. By identifying weaknesses at an early stage, the engineers can take measures to fix problems before using the machine in production, which prevents wasted time and money and improves outcomes.

Importance of FMEA in Businesses

1. Preventing Risk: Using Failure Mode and Effects Analysis helps companies identify problems early and can help businesses prevent issues before they escalate into serious problems.
2. Cost Savings: By preventing errors in the first place, companies will save the cost of repair, recalls, or lost production.
3. Safety: Using FMEA can improve the safety of products and processes for the safety of workers and customers.
4. Quality: Using FMEA, an example widely used in industries such as automotive or electronics, helps improve the overall quality of products.
5. Trust: Consistently providing reliable products through Failure Mode and Effects Analysis can improve customer trust and loyalty.

Streamline Your Project Workflow

Organize tasks, manage teams, and achieve milestones with clarity and control.

Explore Program

Types of Failure Mode and Effects Analysis

There are basically two types of Failure Mode and Effects Analysis (FMEA). Both are commonly used in industries, with different objectives.

1. Design FMEA (DFMEA)

Design FMEA is performed in the design stage of the product. Essentially, the purpose is to review potential failure modes with the design and subsequent effects on the final product. For example, in a company that creates smartphones, they might use Failure Mode and Effects Analysis to see whether the design of the battery would affect performance successfully to prevent it from overheating. If a potential failure mode and effect is identified, they have the opportunity to redesign the component to avoid a problem in the future.

2. Process FMEA (PFMEA)

Process FMEA is similar to the Design FMEA, but instead of investigating failures on product design, they are used to investigate failures in a process. In PFMEA, you would look at each process step in the production and consider each step, and determine whether problems could occur in the step. Following an example in a food company, Failure Mode and Effects Analysis is useful for identifying risks such as a machine breakdown or improper mixing. Identifying risks and problems ahead of time allows you to control that they are accounted for and isolated, allowing the company to run smoothly and safely.

FMEA Levels and Scope

1. System Level: The FMEA is done on the entire system to determine how one component’s failure affects the entire system.
2. Subsystem Level: The FMEA can now be conducted on subsystems composed of smaller units. The failure mode of one unit can be studied to predict larger failures.
3. Component Level: This applies to the FMEA on the smallest units of product or process to determine if and when they will fail.
4. Process Level: This scope looks at every single step taken in a process. An example of an FMEA would be reviewing a production line for errors in sequence, tools, or methods.

Why and When to Perform FMEA

Understanding the need to perform Failure Mode and Effects Analysis is important for every business. It makes sure that the risks are reduced, quality is improved, and the process remains reliable. Let’s explore the why and when FMEA is performed.

Why Perform FMEA?

1. Risk Identification: FMEA identifies possible risks before they occur.
2. Cost Savings: It helps prevent costly repairs, recalls, and rework.
3. Quality Improvement: Products and processes become much more reliable with FMEA checks.
4. Customer Confidence: Higher quality, safer products build customer trust in your organisation for the long term.

When to Perform FMEA?

1. Designing a New Product: Complete Failure Mode and Effects Analysis in design will identify areas of vulnerability.
2. Launching New Process: Use FMEA before introducing a new process to avoid future breakdowns.
3. Changes in System or Process: Engage in FMEA before making changes for new technology, new tools, or new methods.
4. Continuous Improvement: Engage in FMEA regularly as part of process controls to be proactive in eliminating hidden risks.

How to Perform Failure Mode and Effects Analysis

Let’s explore the steps of how to perform FMEA in detail:

Step 1: Identify the Process or Product

The initial part of the Failure Mode and Effects Analysis is to identify the process, product, or system you are looking to analyze. Without identifying this specifically, it is hard to identify potential risks. For example, in a manufacturing facility, a particular production line or a single machine can be analyzed for FMEA.

Step 2: List Possible Failure Modes

After you have identified the process or product, list all the ways that process or product could fail. A failure mode could be a machine failure, a design flaw, or an error in a step. In one example of FMEA, a car brake system could have a failure mode like “brake pads wearing out too fast”.

Step 3: Find the Effects of Failures

Next, examine what will happen if each failure mode occurs. This is the “effects analysis” part. Effects can be anything from safety risks, product damage, customer dissatisfaction, or system downtime. In FMEA, exploring the effects is equally important to understanding the severity of each issue.

Step 4: Assign Ratings

Each of the failure modes is rated based on three criteria:

• Severity (S): What is the seriousness of the failure phenomenon?
• Occurrence (O): What is the likely frequency of this failure mode?
• Detection (D): How difficult is it to detect this before it causes harm?

These ratings are often expressed on a scale (e.g., 1 to 10). This systematization allows us to standardize and quantify the ratings related to the FMEA.

Step 5: Calculate Risk Priority Number (RPN)

RPN is obtained by multiplying Severity × Occurrence × Detection. The RPN indicates which failures need immediate action. In an FMEA example, if a failure, such as a machine fault, has a very high RPN, it must be addressed immediately so losses do not occur.

Step 6: Take Corrective Actions

Once high-risk failures have been identified, teams will plan corrective actions that will eliminate or reduce the risk. Corrective actions could mean changing designs, adding safeguards, or implementing better inspections. In FMEA, correct actions are the backbone of preventing future problems.

Step 7: Review and Update

FMEA is not a one-time activity. After corrective actions have been taken to reduce risk, the process of failure modes and effects analysis should be given ongoing consideration. To stay on top of changing risks, the FMEA should be updated. If failure modes are updated regularly, new risks can be identified and risk management actions taken on time. Ongoing assessment ensures quality, safety, and efficiency levels remain high.

Tools and Software for FMEA

Let’s explore the tools and software required for Failure Mode and Effects Analysis:

1. Spreadsheet Tools: Spreadsheet tools like Excel or Google Sheets are common tools for FMEA because they are simple to use.
2. Dedicated FMEA Software: Dedicated tools like APIS IQ-RM, Xfmea, or ReliaSoft help automate the flow of FMEA.
3. Quality Management Systems (QMS): Some organizations use full QMS platforms with FMEA template options.
4. Collaboration Tools: Teams often make use of a dedicated online tool like Minitab Workspace or other project tools to collaborate, share, and track FMEA outputs.

Failure Mode and Effects Analysis Examples

Let’s explore the examples of FMEA:

1. Manufacturing Example: In a car manufacturing facility, engineers use an FMEA to evaluate the braking system. If they identify that the brake pads wear out too quickly (failure mode), the potential effect could be reduced safety. Addressing this early leads to improved safety and reliability.
2. Healthcare Example: Hospitals conduct FMEA to evaluate the processes for treating patients. For example, if a medicine is given at an incorrect dosage (failure modes), the effects could be serious harm to patients. The purpose of FMEA is to help design a system that is much safer for the healthcare industry.
3. Electronics Example: In the design of mobile and smartphone electronics, battery design is evaluated by companies that also evaluate battery safety as part of an FMEA. If a battery overheats (failure mode), the potential effects could be product failure or safety risks. If companies identify these risks in the design phase, then the costs of recalls due to safety issues are avoided, and overall margins are improved.

Benefits of Failure Mode and Effects Analysis

Let’s explore the benefits of failure modes and effects analysis:

1. Early Risk Identification: FMEA can identify issues before they affect production or customers.
2. Increased Safety: FMEA will often identify potential accidents and allow for continued safe use of products and systems.
3. Cost Savings: A business saves costs related to rework, recalls, and warranty claims as a result of FMEA.
4. Higher Quality Level: A design or process, by conducting FMEA, can ensure that the final output meets applicable quality and reliability standards.
5. Customer Confidence: Accessorizing good-quality and safe products increases customer satisfaction, which in turn inspires customer loyalty and brand trust.
6. Continuous Improvement: FMEA is a long-range process. It encourages teams to routinely review and improve their processes.

Challenges and Limitations of FMEA

1. Time-consuming: FMEA can often take large amounts of time to perform, especially for complex systems.
2. Subjective Ratings: The severity, occurrence, and detection ratings in FMEA rely on human judgment, which may, in some cases, be impacted by bias.
3. Requires Significant Resources: A thorough FMEA requires trained personnel, proper data collection, and specialized tools, all of which involve costs.
4. Incomplete Analysis: If some failure modes are missed by teams, then the FMEA example is incomplete and inaccurate.

Best Practices for FMEA Implementation

Let’s explore the best practices for FMEA Implementation

1. Leverage Data and Evidence: Base your FMEA on data, evidence, previous history, and test data, not assumptions.
2. Focus on High Risk: Concentrate first on the issues with the highest RPN. This way, your failure modes and effects analysis example will yield good results.
3. Keep FMEA Current: Revisit and update FMEA regularly. An outdated report can lead to serious errors.
4. Utilize the Appropriate Tools: Spreadsheets are fine, but dedicated software makes FMEA quicker and more accurate.

Conclusion

Failure Mode and Effects Analysis is an effective way to anticipate, prevent, and resolve issues before they negatively impact businesses. With the ability to identify risks early in development, businesses can save money, improve safety, and produce quality products that customers can depend on. In any industry, from manufacturing to healthcare to technology, Failure Mode and Effects Analysis is an important component of sustainable long-term success. With the proper team, tools, and data updates, FMEA is an important tool for continuous improvement.
