KPI Visuals in Power BI

KPI Visuals in Power BI

KPI, also called Key Performance Indicators, are important visuals in Power BI that allow businesses to track their performance against certain goals. KPIs help track a business’s progress, evaluate its performance, and highlight areas where improvements can be made to enhance overall productivity. In this blog, let us understand KPI and their visualization with advantages.

Table of Contents:

What are KPIs in Power BI?

KPIs are indicators that are used to evaluate the success or failure of an organization, team, or individual. These are very important visuals that are offered by Power BI, which are used to track profit margins, sales growth, or customer analysis. KPI presents clear information and provides exact details that help in easily fetching information.

Power BI offers different visuals to represent KPIs, like

  • KPI visuals
  • Gauge visuals
  • Card Visual

Advantages of Visualizing KPIs in Power BI

  • Power BI allows businesses to monitor KPI trends live without refreshing reports, as it connects to real-time data sources.
  • Power BI offers different KPI visuals that allow users to select different KPIs according to their needs.
  • KPI helps stakeholders make decisions by referring to performance measures represented by KPI.
  • KPI helps businesses to identify strong and weak spots.
  • DAX with KPI brings more features and makes customizable and highly interactive reports, which help uncover deeper insights.

Data Represented by KPIs

Example Dataset:

Let us use a dataset to create KPIs.

DateProductSalesProfit
2024-01-01Product A1000200
2024-01-01Product B1500250
2024-02-01Product A1200240
2024-02-01Product B1300180
2024-03-01Product A1100210
2024-03-01Product B1600300

Step 1: Load the Dataset into Power BI

Click Home>Get Data>Text/CSV

Load the Dataset into Power BI

After following the steps, your data will be loaded into Power BI.

Power BI

This is what your dataset will look like.

Step 2: Create KPI Measure with DAX

Go to the Modeling Tab> New Measure and write the following formula.

1. Profit Margin:

Profit Margin = DIVIDE(SUM(SalesData[Profit]), SUM(SalesData[Sales]))

2. Profit Margin Target:

Profit Margin Target = 0.15

3. KPI Profit Margin vs Target (for Card visual)

KPI Profit Margin vs Target =

VAR Diff = [Profit Margin] - [Profit Margin Target]

VAR Sign = IF(Diff > 0, "+", "")

RETURN

"Goal: " & FORMAT([Profit Margin Target], "#0%") & " (" & Sign & FORMAT(Diff, "#0.0%") & ")"

3. KPI Color

KPI Color =

VAR Diff = [Profit Margin] - [Profit Margin Target]

RETURN

SWITCH(

TRUE(),

Diff > 0, "Green",

Diff < 0, "Red",

"Black"

)

KPI Visuals

A KPI visual is a special graph used to display performance metrics by comparing actual values against predefined targets.

Steps to create KPI:

Go to Report view and select  KPI visual from the visualization pane

Drag:

  • Indicator: Profit Margin
  • Trend axis: Date
  • Target goal: Profit Margin Target

Output:

KPI Visuals

Explanation: Here, this graph represents the KPI Visuals, which show:

  • Actual Profit Margin: 0.19
  • Target (Goal): 0.15
  • Performance: +25.93 % above the goal, marked with a green tick.

Card Visual

Card Visual in Power BI is a simple visual used to display a single, important data point

Steps to create Card Visual:

Select the Card visual from the visualization pane and drag the KPI Profit Margin vs Target.

Output:

Card Visual

Explanation: Here, this graph shows a card visual, which is used to show:

  • Goal: 15%
  • Current Status: +2.9% (showing a small improvement over the goal).

Gauge Visual

Gauge Visual in Power BI is a circular visual used to show progress toward a target by comparing a single value against a defined goal.

Steps to create Gauge Visual:

Select Gauge Visual from the visualization pane and

Drag:

  • Value: Profit Margin
  • Target Value: Profit Margin Target

Output:

Gauge Visual

Explanation: The Gauge is used to compare the actual performance (01.8) against the target value (0.15).

Performance Considerations

Visual Performance Considerations
KPI VisualKPIs require minimal resources to work and perform very well with data that is aggregated, and they are best used when there is a need to show a comparison between actual and targeted values.
Card VisualCard visuals are faster and show minimal impact on a report’s performance, and they are best used to display a single value.
Gauge VisualGauge visuals require more resources to render and are best used for small datasets. It can result in performance issues if used more than once in a single report.

Limitations of KPI Visuals in Power BI

Visual Limitations
KPI VisualThere is a lack of customization.It is only used to represent comparisons between two values.There is no option to use conditional formatting.
Card VisualA card visual only displays one value per card.It can not be used to show comparisons.There is no interactivity between values.
Gauge VisualGauges are not suitable for large amounts of data.It is only used to show specific information.It takes more space on the report to show only one piece of information.

Best Practices

  • Try to keep your visuals simple and only show important information.
  • Try to use colours like green and red for denoting rise and fall, which helps in better understanding.
  • The KPIs should reflect strategic business objectives and make sure that insights are actionable.
  • If you are comparing performance, try to use leading and lagging data, which helps you to compare performance.
  • Update your KPIs regularly, as they are built on live data. If live data changes, the KPI also changes.

Conclusion

KPIs in Power BI help organizations to track performance, identify trends, and take action based on patterns. By visualizing business metrics in real time, businesses can easily track their progress toward goals, spot areas that are performing well, and address areas that need improvement. KPIs are used to improve efficiency, improve customer experience, or increase profitability. KPIs in Power BI help stakeholders or clients to understand their business’s growth.

To learn more about Power BI and its functions, check out this Power BI Course and also explore Power BI Interview Questions prepared by industry experts.

KPI Visuals in Power BI – FAQs

Q1. What is a KPI in Power BI?

KPIs are called Key Performance Indicators, which help to track performance against specific targets.

Q2. How do I calculate KPIs in Power BI?

We can calculate KPI by writing a DAX formula.

Profit Margin = SUM(Profit) / SUM(Sales)
Q3. How do I set a target value for a KPI?

You can set a target value for KPI by writing a DAX formula

Example:

Profit Margin Target = 0.15
Q4. What’s the difference between a KPI and a regular measure?

Regular measures are calculated values, while KPIs are visual representations of those values.

Q5. How do I display multiple KPIs on one report page?

You can use different KPI visuals, like KPI visuals, gauges and cards
