Data visualization is important for understanding data. Power BI has a lot of charts and other ways to present your data, making it a lot easier for your audience to understand it. The Pie chart is one of those charts that have always been very popular because of its simplicity and visualization. Understanding pie charts is important because pie charts are mainly used to visualize the distribution of data across several different categories. We will take a look at pie charts in Power BI, how to use them, and how to create them step-by-step in this blog.

Table of Contents:

What is a Pie Chart?

A Pie Chart in Power BI is a circular statistical graph that uses slices to compare numerical proportions. Each slice represents a part’s contribution to the total value. The entire circle represents 100%, and each slice visually shows how much each part contributes to that whole. Pie charts are great for showing the relative sizes of different categories, which helps users easily understand the distribution of data.

When to Use Pie Charts:

  • When you want to show the proportion of the whole.
  • When you want to compare a small number of categories.
  • The categories are mutually exclusive and do not overlap.
  • You want to provide a high-level summary.

How to Customize Pie Charts in Power BI?

Customizing a Power BI Pie Chart is essential for improving both readability and visual appeal. While the default configuration of a Pie Chart in Power BI gives a quick snapshot of data, refining it ensures that your audience can interpret the chart accurately and quickly.

1. Limit the Number of Slices

  • A cluttered pie chart with too many slices can be hard to read.
  • Best practice: Use no more than 3–5 categories for clarity.
  • If your dataset contains more categories, consider alternatives to pie charts in Power BI, such as bar or stacked column charts.

2. Use Distinct and Contrasting Colors

  • Assign a unique color to each slice using the Data colors option in the Format pane.
  • Avoid using similar shades, which can make slices indistinguishable.
  • Good color contrast enhances user comprehension and supports accessibility.

3. Add Data Labels for Clarity

  • Turn on Data Labels to display either:
  • Percentage of total
  • Actual values
  • Or both
  • Labels reduce guesswork and help users quickly identify what each slice represents.

4. Customize Legends

  • Enable and position the Legend (top, bottom, left, right) depending on available space and layout preference.
  • A well-placed legend helps users identify categories without cluttering the chart.

5. Sort Slices for Better Comparison

  • In the Fields pane, click on the dropdown for the category and choose Sort by:
  • Value (ascending or descending) for easier comparison.
  • This ensures the most significant segments appear first, making the chart easier to interpret.

6. Customize Tooltips

  • Tooltips in Power BI Pie Charts show extra data when a user hovers over a slice.
  • Use the Tooltip field in the visual to add more context, such as:
    • Year
    • Region
    • Salesperson
  • This enhances interactivity and provides more insights without overloading the visual.

7. Adjust the Slice Explosion (Optional)

  • Use the Detail labels > Style > Callout value or Slice Explosion to pull out a specific slice.
  • Useful for emphasizing key data points like top-performing categories.

8. Turn Off Title, Background, or Border (Optional)

  • In some dashboards, disabling these elements reduces visual noise.
  • Use this option when embedding your Power BI Pie Chart within a dense report layout.
    In some dashboards, disabling these elements reduces visual noise.

Data Represented by a Pie Chart in Power BI

Example Dataset:

Let us use a dataset to create a Pie chart.

CategorySales Amount
Electronics35,000
Clothing20,000
Groceries15,000
Furniture10,000
Books5,000

Step 1: Load the Dataset into Power BI

Click Home>Get Data>Text/CSV

Load the Dataset into Power BI

After following the steps, your data will be loaded into Power BI.

data will be loaded into Power BI

This is what your dataset will look like.

Step 2: In the Visualization Pane,

Click on the pie chart icon and drag the chart onto your canvas.

Visualization Pane,

Step 3: Assign Data Fields

  • Drag the Category to the legend field.
  • Drag the Sales amount to the values field.
Assign Data Fields

Output:

pie chart

Explanation: This is how the Pie chart looks once it is created, which is used to compare the sales data across different categories.

How to Understand the Pie Chart

Now that you have created a pie chart, here’s how to read it.

  • Size of Slice: Indicates the proportion of sales each category contributes.
  • Color Coding: Helps identify categories at a glance.
  • Labels: Show both the sales amount and percentage of total.

Example Interpretation:

From the example pie chart:

  • Electronics has the largest slice (43.7%)
  • Books have the smallest (6.25%)
  • We can see that Electronics dominates sales, followed by Clothing.

Best Practices for Pie Chart

  • Number of Slices: When you are using a pie chart for interpretation, make sure it doesn’t contain many slices; Limit the number of slices (3-5).
  • Use colors: When using a pie chart, use different colors for each slice, which helps you to differentiate them easily.
  • Use labels: Try to include percentage labels, as they are easier to understand.
  • Sort: Try to sort the slices either from largest to smallest or from smallest to largest.

Common Pitfalls

  • Overcrowding: Including too many categories in a pie chart causes tiny slices, which makes it hard for viewers to quickly understand the data distribution.
  • Ambiguous colours: Avoid using similar colours, which can make slices look identical and create confusion for viewers in identifying which slices represent which category.
  • No Labels: Without data labels, users are forced to guess the values or percentages. Labels provide clarity and context, which makes the chart more interactive.

Alternatives to Pie Charts in Power BI

If your data becomes too complicated or crowded, you can use a better visualization by following a few alternatives to Pie Charts in Power BI:

Bar Charts

  • A Bar Chart is better for comparing when you have multiple values side by side.
  • Easier to read when the values are close.

Stacked Column Charts

  • Stacked Column Charts show part to whole in a vertical layout.
  • It is good for showing change over time across segments.

Donut Charts

  • It is very similar to a pie chart but has a central blank space.
  • It is used for making your dashboard aesthetics, but also has some limitations.

Pie Chart vs Donut Chart Power BI

Feature Pie Chart Donut Chart
Center Space Fully filled circle Has a blank center (ring-shaped)
Visual Style Traditional circular design Sleeker, minimal design
Data Label Area Labels placed around the chart Labels can also be placed in the center
Dashboard Fit Takes more space Fits better in space-limited dashboards

Power BI Pie Chart Use Cases in Real Projects

Pie Chart in Power BI is widely used across industries to simplify data distribution and support decision-making. Here are some common real-world applications:

1. Retail Analytics

Retailers use Power BI Pie Charts to visualize revenue contribution by department. For example, slices may represent sales from electronics, clothing, groceries, etc., making it easy to see which categories drive the most income.

2. Marketing Dashboards

Marketers use Pie Charts in Power BI to show the percentage of leads from various sources, like email, social media, or paid ads. This helps in reallocating marketing spend effectively.

3. Financial Reporting

Finance teams use Power BI data visualization tools like pie charts to display how expenses are distributed across departments (e.g., HR, Operations, IT). This simplifies budget analysis.

4. Project Management

Project managers leverage Power BI Pie Charts to show how resources or time are allocated across different phases or teams, ensuring balanced workload and better planning.

Conclusion

Pie charts in Power BI are a simple but powerful way to express information to the audience. When used correctly with a limited number of categories, clear labels, and distinct colors, they can deliver information quickly. However, they must be used with caution to avoid common pitfalls, such as overcrowding and misleading designs. By understanding their strengths and limitations and knowing when to consider alternative visuals, you can create pie charts for presenting information.

To learn more about Power BI and its functions, check out this Power BI Course and also explore Power BI Interview Questions prepared by industry experts.

Learn how Power BI integrates with SQL Server to turn raw data into actionable insights in the articles below

Web Scraping in Power BI – Step-by-step guide to web data extraction using Power BI.

Bar and Column Charts in Power BI – Design impactful bar and column charts in Power BI.

Join Tables in Power BI – Using relationships to join tables in Power BI.

Calculate Running Total in SQL Server – SQL Server script for computing cumulative totals.

Pie Charts in Power BI – FAQs

Q1. When should I use a pie chart in Power BI?

Use a pie chart when you want to show proportions of a whole using a small number of distinct categories.

Q2. How to create Pie Chart in Power BI?

To create a Pie Chart in Power BI, select the Pie Chart visual from the Visualizations pane, then drag a categorical field to “Legend” and a numeric field to “Values”.

Q3. Can I show both value and percentage in a Power BI pie chart?

Yes, you can show both value and percentage in Power BI.

Q4. What’s the difference between a pie chart and a donut chart in Power BI?

A donut chart is essentially a pie chart with a blank center. It offers a cleaner look and fits better visually in dashboards.

Q5. How do I customize the colors of each slice?

Go to the Format pane > Data colours and manually assign colours to each category for better contrast and clarity.

Q6. Can I drill down into categories in a pie chart?

Yes! If your data has hierarchies, you can enable drill-down functionality to explore subcategories directly within the pie chart.
