Ribbon Charts in Power BI

Power BI offers several visuals and chart types to help you understand the data, but when it comes to displaying changes in ranking over time, there is nothing better than a ribbon chart. Ribbon Charts are now included as a standard visualization option in Power BI. Ribbon Charts are useful for visualizing how values are ranked across different categories. They also help you track how those rankings shift over time. In this blog, you will explore Ribbon Charts with benefits and best practices.

Table of Contents:

• What Is a Ribbon Chart in Power BI and How Does It Work?
• Benefits of Using Ribbon Charts in Power BI
• When to Use Ribbon Charts?
• What Makes Ribbon Charts Unique in Power BI?
• How to Create a Ribbon Chart in Power BI? (Step-by-Step)
• Formatting Options to Enhance Your Ribbon Chart in Power BI
• Understanding Ribbon Width
• Ribbon Chart vs Line Chart vs Bar Chart in Power BI
• Drawbacks and Limitations of Using Ribbon Charts in Power BI
• Common Mistakes to Avoid in Ribbon Charts
• Best Practices for Designing Ribbon Charts in Power BI
• Real-World Business Scenario
• Conclusion

What are Ribbon Charts in Power BI?

Among the many Power BI visuals, the Ribbon Chart stands out as an effective Power BI visual ranking chart to display shifts in order over time. A Ribbon Chart is a Power BI visualization that demonstrates how various categories’ rankings change over time. Each ribbon represents a category and has its position denoting its rank at each point on the timeline. The chart facilitates the identification of increasing or decreasing performance. It is particularly helpful in comparing trends of product sales or market share, and provides a more visual and interactive view of the data.

Advantages of Ribbon Chart in Power BI

• Dynamic rank visualization Power BI: Clearly shows how categories rise or fall in rank over time.
• Improved storytelling: Ribbons flow and capture the viewers’ attention, and narrate complicated data in an understandable way to the audience.
• Temporal comparisons: Ribbon Charts enable the simultaneous performance comparison across multiple categories.
• Power BI interactivity: Users can hover over individual ribbons and see details of how things performed before that day and after, and provide better data exploration and analysis.
• Visual appeal: The unique look of Ribbon Charts makes reports and dashboards look cooler and more visually appealing to others.

When to Use Power BI Ribbon Charts?

Power BI Ribbon Charts offer several advantages in situations where it is important to capture rankings over time. Below are some theoretical considerations and practical considerations:

Theoretical considerations:

• Time Series: Power BI ribbon charts can easily capture temporal data(data that includes time-related information); They are particularly suitable for time series analysis, as the intent is often to identify how data is changing over time.
• Ordinal Data: Ordinal data is both a type of data that conveys rank order and an appropriate venue for using ribbon charts. Power BI Ribbon Chart can highlight changes in an order or rank.
• Comparative Dynamics: For analyses that explore the comparative dynamics of categories, ribbon charts provide easy-to-interpret visuals of how the entities outperform or underperform each other over time.

Use case:

• Sales Performance Tracking: Visualizing the rankings of products or regions in sales over several quarters.
• Market Share Tracking: Visualizing the movements of companies’ shares over time in an industry.
• Individual Performance: Tracking employee selections over evaluation periods and performance ranks.
• Budget Efficiency: Comparing how departments are executing their budgets during the budget year.

Unleash the full power of Power BI – From dashboards to data storytelling!

Enroll now and elevate your analytics game

Explore Program

What Makes Ribbon Charts Unique in Power BI?

1. Emphasis on Rank Over Time
Primary Purpose: ribbon chart in Power BI visualizes rankings of categories across a time axis (e.g., monthly sales rankings by brand).
How: The width and position of each ribbon indicate the rank, not the absolute value.

2. Visual Tracking of Category Leadership
Easily track which category leads at each point in time.
Ribbons flow smoothly from one time period to the next, highlighting leadership changes visually without needing interaction or animation.

3. Dynamic Width Representation
Ribbon width reflects rank, not actual value magnitude.
This makes it ideal for relative comparisons where the order matters more than the exact difference.

4. Highlights, Transitions, and Movement
Unlike line or bar charts, Ribbon Charts in Power BI emphasize movement across ranks.
They make it easy to spot upward or downward trends in competitive positions over time.

5. Built-In Sorting and Stacking
Categories are automatically sorted by value at each time point.
The visual stack adjusts dynamically, making it easy to read top-to-bottom rankings over a timeline.

6. Combines Elements of Multiple Charts
Bar chart: For value-based visualization at a point in time.
Line chart: For tracking trends across time.
Stacked area chart: For showing layered flow, but with rank emphasis rather than cumulative totals.

How to Create a Ribbon Chart in Power BI?

Let’s understand the process of creating a ribbon chart in Power BI with the help of a dataset.

Step 1: Load the Dataset into Power BI

Click Home > Get Data > Text/CSV

After following the steps, your data will be loaded into Power BI.

This is how your dataset looks after being loaded into Power BI.

Step 2: Insert a Ribbon Chart
Click the Ribbon Chart from the Visualization pane.

This is the visualization pane in which all graphs are present.

Step 3: Add Fields

• Axis: Drag Release Year
• Legend: Drag Platform
• Values: Drag Views (millions)

Result:

Explanation: The Power BI Ribbon Chart is used to show the number of people who watched shows on Netflix (dark blue) and Amazon Prime (light blue) each year; A thicker ribbon means that the platform had the highest views that year.

Formatting Options to Enhance Your Ribbon Chart in Power BI

1. Color differentiation: The chart shown to the right consists of Amazon Prime and Netflix in different shades of blue.
Consider having the platforms or categories be obviously different by using a contrasting color, like a dark blue for Netflix, and orange or green for Amazon Prime.

2. Ribbon opacity: If the ribbons overlap or obstruct an important aspect of the chart, feel free to lower the opacity to bring forward or allow the background elements to show somewhat.
Go to Format Pane → Ribbon → Transparency to find the opacity levels you need.

3. Data labels: The chart does not show a data value or rank at the moment.
You should turn on Data Labels to show either the rank position or the actual views, especially when determining the width for each is not clear.

4. Legend formatting: The legend uses default colors and default placement.
Consider editing or changing the placement or styles of the legend (i.e., move it underneath the chart, change font size, etc) to align with your report layout.

Understanding Ribbon Width

The width of a ribbon in the Power BI Ribbon Chart does not represent the actual value of the category at that time, but the rank of the category at that time. The category with the highest value (Rank 1) will have the widest ribbon, as rank represents the size of the ribbon, and lower-ranked ribbons will have progressively narrower ribbons. As time moves along the X-axis, categories move location and width as their rank changes over time, creating a flowing effect that dynamically represents rank over time. This does not allow one to compare numbers exactly, but it allows for easier identification of who is gaining or losing rank.

Ribbon Chart vs Line Chart vs Bar Chart in Power BI

Drawbacks and Limitations of Using Ribbon Charts in Power BI

1. Restricted to Comparing Different Ranks
Ribbon Charts are best suited for reviewing and comparing rank charts or ordered values over time. If you are interested in examining raw numerical trends (without any ordering or ranking), a line or bar chart may be a better option.

2. Too Many Categories Cause Overcrowding
Too many categories can clutter the chart, making it difficult to interpret.

3. Intended for time-series data
Ribbon Charts are designed for datasets that include a temporal (time) aspect. If you don’t have a proper date/time axis, the visual loses significance.

4. Limited Customization
The customization options for Ribbon Charts in Power BI are quite limited in comparison to some other visuals in Power BI, such as options for ribbon curvature, spacing, or even displaying exact ranking.

5. Can Mislead Without Context
If not clearly labelled or paired with visuals that provide context, people could confuse what the ribbons represent (e.g., rank versus value). Therefore, it is important to provide visuals with good tooltips and a legend (a key that is used to show what the colors or symbols in the chart represent).

Limitations:

1. Limited to Ranking Visualization

• Ribbon Charts are designed to show rank changes, not actual value trends.
• They’re not suitable if you need to emphasize exact numerical differences between categories.

2. Poor Readability with Many Categories

• With more than 5–10 categories, ribbons begin to overlap and clutter, making the chart hard to interpret.
• There’s no built-in “Top N” filter, so manual filtering is often required.

3. Cannot Display Negative Values

• Ribbon Charts only work with positive values because they rely on rank stacking.
• Any negative or zero values will cause issues or be ignored in the visual.

4. Fixed Time Axis Requirement

• Requires a well-structured, continuous time series on the X-axis.
• Inconsistent or missing time periods can break the visual flow or create misleading gaps.

5. Limited Formatting and Customization Options

• Users may find it difficult to match specific branding or layout needs.
• Compared to bar or line charts, Ribbon Charts have fewer formatting controls (e.g., no conditional formatting, limited label placement).

Common Mistakes to Avoid in Ribbon Charts

1. Using Too Many Categories
   • Problem: Overcrowded ribbons become unreadable.
   • Fix: Limit to 5–10 categories using filters or Top N logic for clarity.
2. Ignoring Time Granularity
   • Problem: Too fine (e.g., daily) or inconsistent time intervals distort trends.
   • Fix: Use consistent intervals like Month or Quarter for meaningful analysis.
3. Not Sorting the Data Properly
   • Problem: Incorrect sorting misrepresents rank changes.
   • Fix: Ensure the axis (e.g., date) is sorted chronologically for accuracy.
4. Wrong Value Aggregation
   • Problem: Choosing Sum vs. Average incorrectly can mislead interpretations.
   • Fix: Select the right aggregation method (Sum, Avg, Max) based on the data.
5. Misinterpreting Ribbon Thickness
   • Fix: Remember: thicker ribbon = higher rank, not necessarily a higher value.
   • Problem: Assuming width reflects value, when it actually represents rank.

Best Practices for Designing Ribbon Charts in Power BI

You can enhance the effectiveness of Power BI Ribbon Charts by following these best practices:

1. Contain the Number of Categories: Avoid excessive categories so that the chart is not crowded with information.
2. Use Different Colors: Ensure that each category has a unique contrasting color for differentiation.
3. Sort Your Data Correctly: Make sure the time axis is sorted appropriately to reflect a progression/productivity over time.
4. Have Context: Having titles and labels, and tool tips promotes better understanding for users.
5. Combine with Other Visuals: Using Ribbon Chart together with other visualizations (for example, bar charts and line graphs) will ensure a more complete analysis.
6. Responsive Page: Make sure it is responsive and displays on other devices.

Real-World Use Cases of Ribbon Charts in Power BI

Scenario: Market Share Analysis Using Power BI Ribbon Charts
A multinational company wants to analyze the market share rankings of its top competitors over the past year. The goal is to understand which brands gained or lost rank in terms of revenue and customer preference.
How Ribbon Charts Are Used:
1. Data Representation:

• The X-axis represents months (Jan–Dec).
• The Y-axis represents total revenue for each brand.
• The ribbons represent different brands, showing their rank changes over time.

2. Insights Gained:

• If a brand’s ribbon moves up, it means its rank improved (higher revenue).
• If a ribbon moves down, it indicates a decline in market position.
• The thickness of the ribbon shows the relative dominance of a brand in a given month.

3. Business Decisions:

• Identify top-performing brands and analyze their strategies.
• Detect declining brands and adjust marketing efforts.
• Forecast future trends based on ranking shifts.

Ribbon charts provide a clear visual representation of competitive dynamics, helping businesses make data-driven decisions. You can explore more about Ribbon Charts in Power BI.

Conclusion

Ribbon Charts in Power BI provide an opportunity to visualize ranking changes over time, which offers a unique experience. Ribbon charts are designed in such a way that allows users to present data effectively and provide detailed analysis. By understanding better practices and appropriately including them in your reports, you can create unique experiences and highlight data in an interesting and informative way.
