Steering geometry is known as a crucial component of vehicle design as it comprises the complex interaction of angles and dimensions that determine how a vehicle reacts to steering inputs. In this blog, we will be enriched with knowledge of steering geometry and its components, along with Ackermann steering geometry.
Click here to watch the Introduction video of the Electric Vehicle Course and learn more about electric vehicles!
What is Steering Geometry?
Steering geometry is known as the value of the lengths and angles inside a steering system, as well as their geometric arrangement. It describes the angle that exists between the front wheels, any components that are mounted to them, and the vehicle’s structure. A steering geometry that is properly adjusted provides predictable and secure vehicle handling, maximizes fuel efficiency, and minimizes tire wear.
Additionally, this geometric configuration of the steering in an automobile addresses how the wheels on the inside and outside of a turn trace out circles with different radii. In simple terms, when a car goes around a curve, the inside wheel and the outside wheel need to follow different paths to make the turn smoothly. The steering geometric configuration manages this requirement effectively. It ensures that the wheels on both sides of the car can follow their respective curved paths, which is crucial for safe and efficient steering during turns.
Steering geometry can be defined easily if the wheelbase, kingpin positions, and moment arm lengths are known.
- The wheelbase is the distance between the front and rear axles of the vehicle.
- The positions of the kingpins, which are center points for the front wheels, play a crucial role in determining the steering behavior and alignment of the wheels.
- The lengths of the moment arms are the distances from the kingpin axis to the various linkages or components in the steering system. These lengths affect factors such as the steering ratio and the Ackermann steering geometry, which are important for proper wheel tracking during turns.
To understand steering geometry in depth, let us discuss its components in more detail in the upcoming section.
Electric vehicles are the future, and our EV Course is the best way to learn about them. Sign up today and start your journey!
Components of Steering Geometry
The steering geometry consists of a number of characteristics and angles that define how the front wheels of a vehicle are positioned in relation to one another. The following are the main elements of steering geometry:
- Caster Angle
- Camber Angle
- King-Pin Inclination
- Toe-in and Toe-out
- Steering Gear Ratio
Caster Angle
The steering axis’s angle when viewed from the side of the vehicle is known as the caster angle. It could be either positive or negative. When the caster angle is positive, the steering axis is tilted toward the rear of the car, while when it is negative, it is tilted toward the front. The returnability of the steering wheel to the center position after a turn is influenced by the caster angle, which also affects steering stability.
Camber Angle
The camber angle is the angle the wheel makes with a vertical line when viewed from the front or back of the car. It may be tilted outward or inward, depending on whether it is positive or negative. A uniform wear of the tires is ensured by proper camber adjustment.
Get 100% Hike!
Master Most in Demand Skills Now!
King-Pin Inclination
When viewed from the front of the car, kingpin inclination (KPI) is an angle produced by a line drawn across the upper and lower ball joints of the steering knuckle and the vertical axis. It improves the steering system’s self-centering action and steering stability.
Toe-in and Toe-out
Toe-in and toe-out are the angles at which the front wheels point in relation to each other when viewed from above. Toe-in, or positive toe, refers to the front wheels being closer together than the rear, while toe-out, or negative toe, refers to the front wheels being farther apart than the rear ones. Tire wear, steering responsiveness, and vehicle stability all depend on proper toe alignment.
Want to crack an Electric Vehicle interview like an ACE, here’s a golden opportunity for you; Top Electric Vehicle Interview Questions!
Steering Gear Ratio
The steering gear ratio, often referred to as the steering ratio, represents the relationship between the movement of the steering wheel and the resulting turning of the front wheels. It indicates how much steering input is needed to turn the wheels of the vehicle. Many factors influence the steering ratio, including pinion diameter, rack travel, steering wheel diameter, and moment arm length.
The steering gear ratio is typically expressed as a numerical value, which describes the number of degrees the front wheels will turn for each degree of rotation of the steering wheel.
Mathematically, it is represented as follows:
Steering Ratio = Arc Sin (C Factor/Arm Length)
In order to get the steering gear ratio, we considered the c factor.
C FACTOR = Rack travel / one rotation of pinion = 100 mm
In this picture, we take into account the typical steering angle and estimate a suitable moment arm length. So we discovered the average rack travel for 360 degrees of rotation.
Steering Ratio = Arc Sin (C Factor/Arm Length) = (90 × 4 × 360/360) = 4.25:1
We have gone through the components of steering geometry. Let’s look into a subset of steering geometry—Ackerman steering geometry.
Learn more about What is an Electric Vehicle in our detailed blog.
Ackermann Steering Geometry
Ackermann steering geometry is a particular design within the broader category of steering geometry. It is named after the 19th-century German engineer Rudolph Ackermann.
Ackermann steering is a geometric arrangement of a vehicle’s front wheels that allows all of the wheels to follow different turning radii when the vehicle turns. This design approach is often employed in automobiles to ensure that a vehicle’s inner and outer wheels handle a turn at distinct angles, allowing for smooth and predictable cornering with minimal tire scraping.
The following are the fundamental characteristics and principles of Ackermann steering:
- Different Turning Radii: When a vehicle turns, the front wheels must follow arcs of varying radii because the outer wheel travels a longer distance than the inner wheel. This variation can be accommodated by Ackermann steering geometry.
- Inner and Outer Wheel Angles: During a turn, the inner wheel is directed at a sharper angle than the outer wheel using Ackermann steering. This means that the inner wheel rotates more, allowing it to follow a smaller radius, while the outer wheel rotates less, allowing it to follow a larger radius.
- Tire Scrubbing: Ackermann steering reduces tire wear and improves vehicle handling by ensuring that the wheels follow their proper radii without excessive slip or scrubbing.
- Center Point Steering: When driving straight, both front wheels should point to the same center point on the rear axle. This alignment is critical for maintaining stability while driving straight.
- Variable Steering Angles: The specific angles at which the inner and outer wheels turn vary depending on factors such as vehicle speed, radius of turn, and wheelbase. These angles are often computed to improve the cornering performance of the vehicle.
Ackermann steering geometry is required for precise and controlled turning in a variety of vehicles, including cars, trucks, and other wheeled vehicles. It is especially crucial in front-wheel-drive vehicles to ensure that the tires do not wear out excessively during turns and that the vehicle handles consistently and safely. While modern vehicles frequently use power steering systems that may somewhat change the geometry, the basic concepts of Ackermann steering remain at the heart of vehicle design.
To calculate the ideal wheel angles, the block uses these equations.
The outside wheel angle depends on the turn direction.
- Right turn
- The outside angle, δo, is the left wheel angle, δL.
- The inside angle, δi, is the right wheel angle, δR.
- Left turn
- The outside angle, δo, is the right wheel angle, δR.
- The inside angle, δi, is the left wheel angle, δL.
The illustration and equations use these variables.
| δin | Steering angle |
|---|
| δL | Left wheel angle |
| δR | Right wheel angle |
| δo | Outside wheel angle |
| δi | Inside wheel angle |
| pAck | Ackerman percentage |
| TW | Track width |
| WB | Wheel base |
| γ | Steering ratio |
Rack and Pinion: The gears convert the steering rotation into linear motion for ideal rack-and-pinion steering.
The illustration and equations use these variables.
| δin | Steering wheel angle |
| δL | Left wheel angle |
| δR | Right wheel angle |
| TW | Track width |
| r | Pinion radius |
| ΔP | Linear change in rack position |
| D | Distance between the front axis and rack |
| lrack | Rack casing length |
| larm | Steering arm length |
| lrod | Tie rod length |
Parallel: For parallel steering, the wheel angles are equal.
The illustration and equations use these variables.
| δin | Steering wheel angle |
| δL | Left wheel angle |
| δR | Right wheel angle |
| γ | Steering ratio |
Join the Revolution: Explore Career Opportunities in Electric Vehicles!
Wrap-Up
Lastly, steering geometry is critical to the safe and efficient running of vehicles. A thorough balance of angles and alignments, such as caster, camber, toe, and Ackermann steering principles, is required to guarantee that a vehicle handles reliably, maintains stability, and has even tire wear. Properly adjusted steering geometry not only improves driving safety but also improves fuel efficiency and lowers maintenance costs. Regular wheel alignment checks and modifications are required to maintain these critical geometric parameters, which allow cars to handle the road with accuracy and reliability while maximizing their lifespan.
