Flexbox in CSS: A Complete Guide


The CSS Flexbox is a strong tool to design the layout with minimum code and maximum flexibility. Understanding Flexbox is so important to create a web page or mobile application in the modern web development era. In this Flexbox guide, we will discuss Flexbox and its flexibility for creating websites.

Table of Contents:

What Is CSS Flexbox?

CSS Flexbox layout provides a one-dimensional system that allows you to arrange elements in either rows or columns. You can distribute the space between the items and the alignment capacity. The items inside the flexbox allow you to grow, shrink, and wrap based on the availability of the space. Therefore, it is suitable for making a responsive layout using flexbox.

Why Use Flexbox for Modern Web Design?

Flexbox is a very useful tool in modern web design because it has a number of advantages. It simplifies complex layouts and helps you to understand how to use flexbox in CSS.

  • You can use it to simplify complex layouts.
  • It handles both horizontal and vertical centering features.
  • You can eliminate float and clearfix.
  • It provides you with fine control over spacing, alignment, and sizing.
  • You can also make a responsive design using flexbox.
Beginner-Friendly Courses to Learn Web Development
Top Web Development Courses
quiz-icon

Flex Container and Flex Item Properties

There are some CSS Flex properties available for flex containers and flex items. Let us discuss them below.

Flex Container Properties

These CSS flex properties are applied to the parent element, which becomes the flexbox container.

Property Definition Syntax
display Defines a flex container display: flex;
display: inline-flex;
flex-direction Sets the direction of the main axis flex-direction: row | row-reverse | column | column-reverse;
flex-wrap Controls whether items wrap onto multiple lines flex-wrap: nowrap | wrap | wrap-reverse;
flex-flow Shorthand for flex-direction and flex-wrap flex-flow: row wrap;
justify-content Aligns items along the main axis justify-content: flex-start | flex-end | center | space-between | space-around | space-evenly;
align-items Aligns items along the cross axis align-items: flex-start | flex-end | center | baseline | stretch;
align-content Aligns wrapped rows along the cross axis align-content: flex-start | flex-end | center | space-between | space-around | stretch;

Flex Item Properties

These properties are applied to the children elements directly inside the flexbox container.

Property Definition Syntax
order Controls the visual order of flex items (lower values appear first) order: 0;
flex-grow Defines how much a flex item can grow relative to others flex-grow: 1;
flex-shrink Defines how much a flex item can shrink relative to others flex-shrink: 1;
flex-basis Sets the initial main size of a flex item flex-basis: auto | 0 | 100px;
flex Shorthand for flex-grow, flex-shrink, and flex-basis flex: 1 1 0;
flex: auto;
align-self Overrides align-items for individual flex items align-self: auto | flex-start | flex-end | center | baseline | stretch;

Most Common Flexbox Layout Patterns with Examples

Understanding these patterns is important to know how to use flexbox in CSS for practical applications. This section acts as a mini flexbox layout tutorial for beginners, so let’s start with a few examples.

How to Center an Element Using Flexbox

You can center an item using CSS Flex properties. This is one of the most powerful features of Flexbox.

Example:

Html

Output:

Centering an Item

Creating Equal-Width Columns with CSS Flexbox

You can give an equal-width column using the Flexbox. The “flex: 1;” property is a shorthand that tells items to grow and shrink equally, making it perfect for an even flexbox layout.

Example:

Html

Output:

Equal Width Columns

Designing a Sidebar Layout Using Flexbox

A common web design pattern, the sidebar, can be efficiently created using CSS Flexbox.

Example:

Html

Output:

Sidebar Layout

Flexbox Debugging Tips

Debugging your CSS Flexbox layouts can save a lot of time. So, let’s know some debugging tips.

  • You can use browser DevTools to inspect and adjust properties.
  • Apply background colors to visualize item spacing.
  • Use an outline for debugging without affecting the Flexbox layout.

Get 100% Hike!

Master Most in Demand Skills Now!

Difference Between Flexbox and Grid

Understanding the difference between justify-content and align-items is crucial for both Flexbox and Grid.

Feature Flexbox Grid
Layout Type One-dimensional (row or column) Two-dimensional (rows and columns)
Main Use Aligning and distributing items in a single line Building full-page or section layouts
Direction Control Uses flex-direction for layout flow Uses rows and columns defined with grid-template
Content Placement Places items relative to each other Places items in specific cells of a grid
Easier For Navigation bars, buttons, and small item lists Full layouts, image galleries, complex UIs
Gap Handling gap works in flex (CSS3), but not as powerfully Full control with grid-gap / gap
Browser Support Widely supported and stable Also well supported (slightly newer than Flexbox)

When Should You Use Flexbox Over Grid or Float?

  • You can use Flexbox when you want to arrange items in a single row or column.
  • Flexbox is best for small layouts, like navigation bars, buttons, or form fields.
  • You can use Flexbox when you want the items to grow, shrink, or wrap based on screen size, facilitating responsive design using Flexbox.
  • You can use Flexbox for simple, flexible, and responsive layouts.
  • Avoid using float for layout purposes, because it is an old method and harder to manage.
  • You can use Grid instead of Flexbox when you need a layout with both rows and columns.
  • Flexbox is helpful when you need to center items easily on a page or inside a container.

Real-World Examples of Using Flexbox Layout

These examples illustrate the versatility of Flexbox in CSS in creating common web components. They demonstrate how to use flexbox in CSS for various UI elements.

1. Navigation Bar: You can use Flexbox to align menu items like Home, About, and Contact in a single row. Using justify-content: space-between; spreads them out evenly across the navigation bar. This is a classic flexbox layout example.

nav {
display: flex;
justify-content: space-between;
}

2. Button Group: Flexbox makes it easy to place buttons next to each other in a row. Apply display: flex; to the button container to line them up side by side.

.button-group {
display: flex;
gap: 10px;
}

3. Card Layout: Flexbox lets you arrange product cards in a row that wraps to the next line on smaller screens. Use display: flex; flex-wrap: wrap; on the container to make this a responsive layout using Flexbox.

.cards {
display: flex;
flex-wrap: wrap;
gap: 20px;
}

4. Form with Aligned Fields: Flexbox helps place input fields and their labels next to each other in a clean row. Apply display: flex; align-items: center; to the container for proper alignment. This uses CSS Flex properties effectively.

.form-row {
display: flex;
align-items: center;
}

5. Centering Elements: Flexbox makes it easy to center a box or message both vertically and horizontally. Use display: flex; justify-content: center; align-items: center; on the parent container.

.center-box {
display: flex;
justify-content: center;
align-items: center;
height: 100vh;
}

6. Responsive Footer: Flexbox allows footer sections to align in a row and wrap on smaller screens. Use display: flex; flex-wrap: wrap; justify-content: space-between; for a responsive footer layout using flexbox.

footer {
display: flex;
flex-wrap: wrap;
justify-content: space-between;
}

How Flexbox Helps With Responsive Design?

Flexbox is a powerful tool for creating a responsive layout using flexbox that adapt seamlessly to different screen sizes. This is a key part of how to use flexbox in CSS for modern web development.

  • Flexbox makes it easy to create responsive layouts that adjust to different screen sizes.
  • It works in one direction (row or column), ideal for menus, buttons, and lists.
  • With flex-wrap, items can wrap to the next line when space runs out, enhancing responsive design using flexbox.
  • The justify-content and align-items CSS Flex properties help control spacing and alignment without extra code.
  • You can use flex-grow and flex-shrink to let items resize based on available space.
  • It helps keep elements centered and balanced on various screen sizes.
  • Flexbox reduces the need for complex media queries in many cases.
  • It is ideal for building clean, flexible, and mobile-friendly layouts.

Conclusion

Flexbox is a tool for designing the layout that gives you a responsive webpage. You can master the CSS Flex properties and understand its items for creating powerful and adaptive layouts in every screen size. You can refer to this Flexbox guide if you need a refresher on Flexbox basics, or to understand how to use Flexbox in CSS is crucial for modern web development.

Explore essential CSS interview questions to enhance your chances of success

What is CSS Flexbox? – FAQs

Q1. What is Flexbox in CSS?

It is the layout model in CSS for arranging the items with flexibility in the container.

Q2. What are the main flex container properties?

There are properties like display, flex-direction, justify-content, align-items, and flex-wrap.

Q3. What properties are available for items inside the container?

There are some properties available for the items, such as flex, align-self, and order.

Q4. What is the difference between justify-content and align-items?

You can use justify-content for aligning the items horizontally, and align-items are used for aligning vertically.

Q5. What is the purpose of flex-wrap?

You can use flex-wrap to control the items to wrap onto new lines.

Q6. How do I center an element using Flexbox?

You can use display: flex; justify-content: center; align-items: center; on the container.

Q7. Can I use Flexbox for mobile responsive design?

Yes, Flexbox is widely used to create mobile-friendly and responsive layouts.

Q8. Does Flexbox work in all browsers?

Yes, Flexbox is supported in all modern browsers, including Chrome, Firefox, Safari, and Edge.
