EVs, short for Electric Vehicles, are machines whose architecture involves several components to deliver efficient and eco-friendly mobility. They comprise rechargeable batteries with electricity rather than utilizing fossil fuels like petrol or diesel. Electric vehicles are more efficient, sustainable, less expensive, and reduce carbon emissions.
In this blog, we explain the electric vehicle components and how these play a key role in the functioning of the EV.
Electric Vehicle and Its Working Principle
Electric vehicles play a key role in combating climate change globally by reducing emissions and dependence on fossil fuels. EVs offer a much-reduced cost of ownership when compared to typical ICE-powered versions. These offer lower running costs to acquire than petrol or diesel vehicles, and are also easier to maintain. This is because electric vehicles have fewer components than conventional automobiles.
A battery pack, power electronics controller, electric motor, and charge port are the main components of an electric automobile. Let’s understand in detail how an electric motor works:
- Battery Charging: When you recharge the battery, the battery pack retains electric current. The stored energy powers the electric motor and other accessories or components.
- Power Distribution: The controller manages the supply of power to the motor.
- Accelerator Input: Depending on the data generated from the accelerator pedal, the controller controls the flow of power.
- Motor Activation: The electric motor draws energy from the battery and transforms it into mechanical energy.
- Power Transmission: The transmission is responsible for transferring mechanical power from the motor to the wheels.
- Regenerative Braking: Some EVs generate braking energy through regenerative braking. The energy created during vehicle braking or deceleration flows back to the battery pack.
Become an EV expert with Hands-on Training!
Electric Vehicle Training Program
Types of Electric Vehicles
It is important to understand the different types of electric vehicles to appreciate the versatility and adaptability of EV technology. Each type serves different needs and preferences, making EVs accessible to a wider audience. Here are the four types of electric vehicles:
1. Battery Electric Vehicles (BEVs): Often known as an ‘All-Electric Vehicle (AEV)’, BEV is a vehicle powered by a battery and a fully electric system.
2. Hybrid Electric Vehicles (HEVs): A Hybrid vehicle is often referred to as a conventional hybrid or a parallel hybrid. HEVs are powered by an internal combustion engine (ICE) as well as an electric motor.
3. Plug-In Hybrid Electric Vehicles (PHEVs): Popular as a series hybrid, PHEVs are hybrid models that contain both ICE and electric motor.
4. Fuel Cell Electric Vehicles (FCEVs): Also known as fuel cell cars (FCVs) or Zero Emission Vehicles. FCEVs are fully electric vehicles that generate energy using “Fuel Cell Technology.”
Components of Electric Vehicles
The main advantage of electric vehicle components is that they emit zero emissions and are eco-friendly. They do not consume any fossil fuels; they use a sustainable form of energy to power EVs. The main components of electric vehicles are:
1. Battery Pack
A battery is a device that stores electric energy. Anode, which is negatively charged, and cathode, which is positively charged, make up a battery. Because there has been an excess accumulation of electrons, which have a negative charge, the anode is negatively charged.
In contrast, a lack of electrons causes the cathode to be positively charged. But the basic workings of an EV battery pack are similar to those of a standard battery. The Electric Vehicle battery pack’s anode and cathode work together to produce power at the most fundamental level within each battery cell.
2. Battery Management System (BMS)
Battery Management System monitors battery health and performance to ensure longer lifespan and optimal efficiency for an electric vehicle.
The integration of BMS ensures complete monitoring of battery cells (charging and discharging) and performance. The system’s real-time alerts and analytics allow users to proactively address battery degradation problems. Thereby extending the service life of their EVs.
3. Electric Motor
The real power behind electric cars is provided by electric motors. The electric motor, together with the batteries and power electronics, is a crucial part of the electric vehicle.
Radial flux is used throughout the EV market. But these days, several electric vehicle manufacturers, like Tesla, have begun to employ axial flux motor technology because of its many advantages, including higher motor power and increased torque density.
Get 100% Hike!
Master Most in Demand Skills Now!
4. DC/DC Converter
The fundamental purpose of DC/DC converters is the same regardless of the underlying model. A step-up converter transforms a low-voltage input into a high-voltage output. On the other hand, a step-down converter does the exact reverse.
An electric vehicle’s batteries generally produce a DC voltage of several hundred volts. Although most EVs operate at significantly lower voltages, the requirements for the electric parts within the car vary.
The traction battery pack provides a steady voltage. But the criteria for various vehicle components vary. The DC-DC converter disperses the battery’s output power to the necessary level. Additionally, it supplies the power needed to recharge the auxiliary battery.
5. Charge Port
The electric car connects to an external source through the charging connector. It charges the battery pack. The vehicle’s front or back may occasionally hold the charging port.
6. On-board Charger (OBC)
An onboard charger converts the AC electricity from the grid into DC supply whenever needed for battery charging. The on-board charger is located and installed inside the car. It monitors various battery characteristics and controls the current flowing inside the battery pack.
7. Transmission
Electric vehicles use a simple single-speed transmission system to transfer power from the motor to the wheels. They use a direct transmission system as opposed to multi-speed transmissions seen in cars powered by fossil fuels. Electric vehicles employ drive mode selectors instead of standard transmission systems, which are less complicated and have fewer moving parts than conventional gearboxes.
8. Controller
The controller’s primary role is to monitor total power sent to the electric motors from the battery and inverter. The controller receives the majority of its feedback from the vehicle’s accelerator pedal (which is set by the driver).
The accelerator pedal regulates the voltage or frequency variations that feed the motor and increases the electric vehicle’s speed.
9. Thermal-System (Cooling/Heating)
EVs need a strong thermal management system to maintain an optimal operating temperature for the battery and other powertrain components. It regulates temperature using a mix of air cooling, liquid cooling, and thermoelectric cooling. It works during charging as well as to get maximum performance, so maintaining proper thermal management is important.
10. Power Electronics Controller
The power control unit converts DC power from the battery into AC power for the electric motor. The drivetrain connects to the accelerator, start button, and drive mode controller via a power control unit. Additionally, it controls regenerative braking, which is how an EV sends energy back to the battery system when slowing.
Future of Electric Vehicles in India
India is the 3rd largest automobile market in the world. The electric vehicle market of India is anticipated to grow to US$191.05 billion by 2034. The country aims to significantly boost EV sales of private cars to 30%, commercial vehicles 70%, buses 40%, and 2 & 3 wheelers to 80% by 2030. This shows the strong future potential of electric vehicles in India.
The rise in automobile ownership should not be construed as a rise in the use of conventional fossil fuels, following the goals of the Paris Agreement. To ensure a positive pace of progress toward India’s Net Zero Emissions by 2070, a mobility transition that will result in more ‘Accessibility’, public transportation, trains, roads, and better vehicle infrastructure is required in India.
Conclusion
Finally, it is important to understand the core components of electric vehicles and how they work together. This helps users to help extend these EVs’ lifespan and ensure optimal functioning. If you are interested in starting a career in the EV domain, enroll in the Electric Vehicle course. In this course, you learn MATLAB, EV design, architecture, and battery technology.
Frequently Asked Questions
Q1. What are EV components?
EV components are the main parts that help an electric vehicle store energy, control power, and move. These components include the battery pack, electric motor, inverter, controller, charging port, and thermal management system.
Q2. What are the major components of an e-power vehicle?
The major components of an e-power vehicle include a battery pack, a power inverter, an electric motor, and a controller.
Q3. How many components does an EV have?
An electric vehicle has around 10-15 components to handle power, drive, and charge.
Q4. What components of an electric vehicle are considered high voltage?
Components of an electric vehicle that are considered high voltage include the battery pack, motor, inverter, and onboard charger. These components typically operate at voltage levels of 200-800 volts, which can pose serious safety risks if not handled properly.
Q5. What is the most expensive component of the EV?
The most expensive component of an EV is its battery pack. It costs 30% to 40% total manufacturing cost of the EV.
