What is Azure ExpressRoute?
Updated on 30th Oct, 21 42 Views

Organizations use cloud services for making their workflows quick and efficient. This work can be confidential at times and having such sensitive workflows on the cloud over the public internet can make them vulnerable to attackers. Thus, having a private connection to the cloud services is necessary to enhance security among other important factors.

In this blog, we will discuss about the secure connection service Azure ExpressRoute through the following topics:

Check out this YouTube video on Azure to learn more:



What is Azure ExpressRoute?

Azure ExpressRoute is a service that, with the help of a connectivity provider, helps us in establishing a private connection to extend your on-premises networks to the Microsoft cloud.

So, Azure ExpressRoute works like a VPN setup between you and the Microsoft cloud. The connection types include point-to-point ethernet network, any-to-any (IPVPN) network, and virtual cross-connection through a co-location facility.

Checkout this Azure Tutorial to learn more about Azure!



Features of Azure ExpressRoute

The key benefits of Azure ExpressRoute include:

  • Multiple connectivity options such as any-to-any (IPVPN) network, point-to-point ethernet network, or virtual cross-connection.
  • Since the connections are made through a private network rather than the internet, it offers low latency, high speed, better reliability, and higher security.
  • The provision of a Layer 3 connection between your local network and the cloud.
  • Connectivity to the Microsoft cloud services from anywhere in the world.
  • There is built-in redundancy, which makes sure that data is replicated at multiple points as a failover measure.
  • ExpressRoute supports a wide range of bandwidths from 50 Mbps to 10 Gbps.
  • Premium and local tiers of ExpressRoute are available, which can be used depending on the geographical and political boundaries.
  • ExpressRoute supports dynamic scaling of the bandwidth without the reconfiguration of connections.
  • If we have multiple circuits of ExpressRoute connected to our on-premises data centers, there is a facility to connect them and the traffic among them will be handled by Microsoft’s networks.

Certification in Cloud & Devops



Azure ExpressRoute Connectivity Options

As mentioned earlier, ExpressRoute provides different connectivity options. Let us take a look at them one by one.

ExpressRoute Connectivity Options


Point-to-point Network Model

Our organization’s data center can be connected directly to the Microsoft cloud using point-to-point connection. ExpressRoute can provide Layer 2 or managed Layer 3 connection between our on-premises data center and the cloud.

Want to become a certified Azure professional and be Industry ready. Check out our Microsoft Azure Certification Training!



Any-to-any Network Model

If your organization and its multiple branches are part of a network, then that network can be connected to the Microsoft cloud by using any-to-any network model. All data centers will be connected to the cloud and the cloud will act as just another branch on the network.



Virtual Cross-connection Network Model

If our organization has set up its data centers at a co-location facility, virtual cross-connections can be made to the cloud. The co-location has to support cloud exchange and the provider can set up Layer 2 or managed Layer 3 connections to the cloud.

Get 50% Hike!

Master Most in Demand Skills Now !



ExpressRoute Direct Connection

Microsoft maintains strategically placed peering locations globally as part of its network. ExpressRoute Direct allows us to connect directly to the peering location and to the cloud.



Azure ExpressRoute Setup

We will see how to set up ExpressRoute step by step in this section:

  • The first prerequisite for setting up an ExpressRoute is an Azure account. Log into the Azure portal using your credentials and click on + Create a resource.
Create a resource
  • Search for ExpressRoute or select ExpressRoute from the Networking tab in the left-hand menu.
 Select ExpressRoute
  • Click on Create and enter the resource group and instance details.
Create ExpressRoute and enter details
  • Move to the Configuration tab and enter the details as per your requirement.
Add configuration details
  • Then go to the Review + create tab and click on Create after reviewing your settings.
Create ExpressRoute
  • After successful deployment, you can configure your on-premises data center to the ExpressRoute created as per your requirements.

Career Transition

Preparing for job interviews? Have a look at our blog on Top 50 Azure interview questions and answers!



Azure ExpressRoute Pricing

ExpressRoute offers metered and unlimited data plans. Outbound data transfers are free in the unlimited plan but charged in the metered plan, while inbound data transfers are free in both plans. The pricing can be different for different zones.

In both metered and unlimited plans, ExpressRoute provides local and premium tiers as well as a standard tier in the unlimited plan. For Zone 1, which includes the US, Canada, parts of Europe, etc., the pricing in metered data plan based on circuit bandwidth, which ranges from $55 per month for 50 Mbps in the local tier to $6,400 per month for 10 Gbps in the premium tier.

In the unlimited plan, the data is charged only from 1 Gbps bandwidth and it ranges from $1,200 per month for 1 Gbps in the local tier to $54,300 per month for 10 Gbps in the premium tier.

The outbound data transfer rates for the metered plan are:

ZonePrice/GB
Zone 1$0.025
Zone 2$0.05
Zone 3$0.14
Zone 4$0.10

For Zone 2, which includes East Asia, Central India, East Japan, South India, West India, US, etc, The pricing in metered data plan based on circuit bandwidth ranges from ₹3,962.49 per month for 50 Mbps in the local tier to ₹4,61,089.664 per month for 10 Gbps in the premium tier.

In the unlimited plan, the data is charged only from 1 Gbps bandwidth and it ranges from ₹1,15,272.416 per month for 1 Gbps in the local tier to ₹61,23,847.1 per month for 10 Gbps in the premium tier.

The outbound data transfer rates for the metered plan for are:

ZonePrice/GB
Zone 1₹1.802
Zone 2₹3.603
Zone 3₹10.087
Zone 4₹7.205

The pricing for various add-ons and direct connections changes with zones. More details about the pricing can be found on the Azure ExpressRoute Pricing page.



Conclusion

Secure connection to the cloud is essential for any organization. Trusting a public network while transferring workflows to the cloud is not safe and Azure ExpressRoute provides a solution for this. The different connectivity and pricing models also offer the users the ability to have multiple options and select the best one for them.

Hope you liked this article, leave a comment about what you think.

If you have any queries, reach out to the Azure Community!
