Hypervisor in Cloud Computing

Introduction to Hypervisor

A hypervisor, also called a virtual machine monitor (VMM), is a software program that creates and runs virtual machines (VMs) on a host machine. Acting as a layer between the hardware and virtual machines, hypervisors allow multiple operating systems to share the resources of a single physical server. This virtualization enables businesses to better utilize server capacity, reduce hardware costs, and simplify operations.

A Cloud Hypervisor is software that creates and runs virtual machines. Hypervisors are a crucial part of the technology that makes Cloud Computing Virtualization possible.

Check out the Cloud Computing Tutorial by Intellipaat.

Types of Hypervisors in Cloud Computing

There are two main types of hypervisors in cloud environments, bare metal hypervisors and hosted hypervisors.

Bare Metal Hypervisors: These are known as Type 1 hypervisors, and run directly on server hardware. This allows for greater performance and efficiency, which is why bare metal hypervisors like VMware ESXi, Microsoft Hyper-V, and Xen are widely utilized in enterprise private clouds as well as by major public cloud providers.

Hosted Hypervisors: These are also called Type 2 hypervisors, and run as an application inside an operating system. Though they utilize more system resources for a given level of performance, hosted hypervisors like KVM, VirtualBox, and VMware Workstation bring advantages like increased portability and easier installation. Developers commonly use Type 2 hypervisors on desktops for building and testing environments.

Want to master Cloud Computing? Get trained with our industry expert on Cloud Computing Courses.

Container Vs. Hypervisor

Container and hypervisor both facilitate sharing physical infrastructure through virtualization, but containers operate at the application layer while hypervisors work at the hardware layer, allowing multiple operating systems per server. Here is the following comparison to help you understand better:

Basis of Comparison	Containers	Hypervisors
Definition	Containers are an operating system-level virtualization method for application isolation	Hypervisors are hardware virtualization techniques that allow multiple VMs on a single server
Abstraction Level	Abstracts and isolates the application layer from the operating system	Abstracts and isolates hardware from operating systems and applications
Overhead	Lightweight with minimal resource overhead	Additional resource overhead is due to full virtualization of guest machine hardware
Speed	Provide faster startup times and performance	Slower startup and performance compared to containers
Flexibility	Limited flexibility as containers share the host kernel and OS	Provides full flexibility to customize virtual guest OS kernels and system libraries
Use Cases	Well-suited for scalable applications and microservices deployment	Well-suited for virtual desktops, portable software development, and testing environments

How Does a Cloud Hypervisor Work?

A cloud hypervisor creates isolated virtual machines by abstracting and partitioning physical server resources like CPU, memory, and storage. This enables running multiple workloads on one server. Within each VM, guest operating systems and applications are installed independently. The hypervisor also handles dynamically allocating resources to VMs based on changing utilization needs using optimization algorithms. This efficient scheduling maximizes infrastructure usage across mixed workloads.

Additionally, the hypervisor layer allows cloud providers to automatically manage provisioning and retiring VMs on demand. By facilitating flexible resource pooling and automation, the hypervisor delivers the scalable, resilient, on-demand compute capacity that defines cloud services.

Advantages of Hypervisor

In the world of cloud computing, hypervisors act as architects, optimizing resources and promoting flexibility. Let’s find their advantages, encouraging businesses toward efficiency and adaptability.

• Resource Optimization: Hypervisors efficiently manage resources, allowing multiple virtual machines (VMs) to run on a single physical server. This optimization maximizes server use, reducing costs and energy consumption.

• Flexibility and Scalability: They offer the flexibility to scale resources up or down based on demand. This flexibility is vital for businesses, as it allows them to adapt to changing needs without investing in additional hardware.

• Isolation and Security: Hypervisors create isolated environments for each VM, preventing issues in one VM from affecting others. This isolation enhances security by, reducing the risk of data breaches and ensuring a more stable system.

• Hardware Consolidation: By consolidating multiple VMs onto a single server, hypervisors save physical space and reduce hardware requirements. This consolidation streamlines management and maintenance efforts.

• Testing and Development: They provide a safe playground for testing new software or applications without impacting the live environment. Developers can experiment without risking the stability of the production environment.

Learn what MNCs ask in interviews with these Top Cloud Computing Interview Questions!

Disadvantages of Hypervisor

While hypervisors offer immense benefits in cloud computing, they also come with potential drawbacks, from performance considerations to management complexities. Let’s explore these disadvantages.

• Performance Overhead: Running multiple virtual machines on a single physical server can lead to performance overhead. This additional layer of virtualization may slightly slow down operations compared to running directly on hardware.

• Resource Consumption: While hypervisors optimize resource usage, there’s still a need for sufficient hardware resources to support multiple virtual machines. This could require an initial investment in hardware.

• Complexity in Management: Managing several virtual machines on a single server can become complex. It requires specialized skills and adds an additional layer of complexity to IT infrastructure management.

• Licensing Costs: Depending on the hypervisor and its features, there might be licensing costs involved, especially for enterprise-level functionalities, adding to the overall expenses.

• Single Point of Failure: If the hypervisor itself encounters issues or fails, it can impact all the VMs running on that server, leading to downtime and potential data loss.

Conclusion

Hypervisor is a key component that enables cloud computing. It allows multiple virtual machines to run simultaneously on a single physical server, maximizing hardware utilization. This virtualization brings significant benefits like flexibility, scalability, and cost savings for cloud users. Overall, hypervisor technology plays a vital role in delivering cloud computing’s promised advantages of on-demand access to computing resources and pay-as-you-go pricing models. It helps cloud service providers efficiently share their infrastructure among many customers in a secure, isolated manner.
